AEC ST3200 - Battery Run Time

User Manual 1-3kVA Rev. 9
- Page 29 of Total 30 -
6. Appendix
` Battery Run Time
Tower
RUN TIME CHART in Minutes
Output load
UPS Mode
l
200 VA
(140 W)
400 VA
(280 W)
600 VA
(420W)
800 VA
(560W)
1000 VA
(700 W)
1500 VA
(1050 W)
2000 VA
(1400 W)
2500 V
A
(1750 W)
3000 VA
(2100 W)
ST3010 60 24 13 8 5
+ 1 EB (6pcs) 243 102 61 42 30
+ 2 EB (12pcs) 451 194 117 81 61
+ 3 EB (18pcs) 675 293 178 124 94
ST3020 210 88 52 36 26 15 9
+ 1 EB (8pcs) 488 210 127 88 66 39 26
+ 2 EB (16pcs) 791 345 210 147 111 66 45
+ 3 EB (24pcs) 1110 488 299 210 159 96 66
ST3030 210 88 52 36 26 15 9 7 5
+ 1 EB (8pcs) 488 210 127 88 66 39 26 19 15
+ 2 EB (16pcs) 791 345 210 147 111 66 45 34 26
+ 3 EB (24pcs) 1110 488 299 210 159 96 66 49 39
Rack Mount
RUN TIME CHART in Minutes
Output load
UPS Mode
l
200 VA
(140 W)
400 VA
(280 W)
600 VA
(420W)
800 VA
(560W)
1000 VA
(700 W)
1500 VA
(1050 W)
2000 VA
(1400 W)
2500 V
A
(1750 W)
3000 VA
(2100 W)
ST3R10 60 24 13 8 5
+ 1 BM (9pcs) 345 147 88 61 45
+ 2 BM (18pcs) 675 293 178 124 94
+ 3 BM (27pcs) 1029 451 276 194 147
ST3R20 210 88 52 36 26 15 9
+ 1 BM (8pcs) 488 210 127 88 66 39 26
+ 2 BM (16pcs) 791 345 210 147 111 66 45
+ 3 BM (24pcs) 1110 488 299 210 159 96 66
ST3R30 210 88 52 36 26 15 9 7 5
+ 1 BM (8pcs) 488 210 127 88 66 39 26 19 15
+ 2 BM (16pcs) 791 345 210 147 111 66 45 34 26
+ 3 BM (24pcs) 1110 488 299 210 159 96 66 49 39
EB: External Battery Bank (for Tower type)
BM: External Battery Module (for Rack Mount type)
Indicates time not calculated, contact sales representative for details.
