6. Appendix
6.1 Specifications
` General Specification
Specifications
Model No.
ST3200 (tower)
ST3200R (rack-mount)
ST3200 (tower)
ST3200R (rack-mount)
ST
3200 (tower)
ST3200R (rack-mount)
Topology True On - Line , Double Conversion
On- battery Output Waveform Pure Sine Wave
Number of Phase Single ( 1 Φ 2W + G )
Input
Maximum Capacity ( VA / W ) 1000 VA / 700 W 2000 VA / 1400 W 3000 VA / 2100 W
Nominal Input Voltage 230 VAC
Input Voltage Regulation 160~300 VAC Single Phase w/ Ground
Nominal Input Frequency 50/60 ± 4 Hz
Input PFC ≧ 0.95
Input Short Protection Circuit Breaker
Output
Nominal Output Voltage 220 / 230 / 240 VAC nominal
Output Voltage Regulation + / - 2 %
Output T.H.D ≦3% ( Linear Load) ≦4% THD ( Linear Load)
≦6% ( Non-Linear Load) ≦7% THD ( Non-Linear Load)
High Efficiency Mode ( AC to AC ) 85% 85% 88%
High Efficiency Mode ( DC to AC ) 83% 83% 83%
Crest Factor 3 : 1
Start on Battery Yes
Output Frequency 50 Hz + / - 0.2 Hz
Overload Sustaining 30 sec @ 125%~150% load; 200ms @ >150% load
Battery
Typical Backup Time ( Full load ) 5 minutes 9 minutes 5 minutes
Battery Type Sealed Lead-Acid maintenance-free 12VDC/7AH per cell
Numbers of Batteries 3 cells 8 cells
Recharge Time to 90% 5 hours
Advance Warning Diagnostics
Front Panel Indication - LCD
UPS Status, I/P Voltage & Frequency, O/P Voltage & Frequency, Battery Voltage,
Battery Capacity, Loading %, Temperature, History Alarm.
Front Panel Indication - LED Normal ( Green ), Warning ( Yellow ), Fault ( Red )
Audible Alarms Battery Mode, Low Battery, Overload, Fault
Communication Interface
Communication port RS232 (Standard); DB9 or USB or AS400 or SNMP / HTTP(Optional)
SNMP Manageable Yes
Environmental
Operation Temperature 0-40℃
Storage Temperature - 15 to 50 ℃
Relative Humidity 20% to 90 % Non-Condensing
Audible Noise
( at 1 meter from surface of unit )
< 45 dBA @ 1 meter < 50 dBA @ 1 meter
Mechanical
Tower Dimensions ( W x H x D
mm )
160 x 220 x 400 200 x 352 x 450 200 x 352 x 450
440 x 88 x 465 ( UPS only )
Rack-mount Dimensions
( W x H x D mm )
440 x 88 x 465
( w/ internal battery )
440 x 88 x 465 ( External Battery Module )
Tower Weight ( Net weight with
Battery ) ( kgs ) 15 34 35
Rack Mount Weight ( Net weight
with Battery ) ( kgs ) 15.5 35 36
