User Manual 1-3kVA Rev. 9
- Page 18 of Total 30 -
3. Operation
3.2 Starting up/ Shutting down the UPS
Starting up the UPS
Step 1. Plug the UPS into an AC wall socket and the UPS will enter Bypass mode.
Step 2. Press the “Select-down” & “Enter” button simultaneously to switch on UPS.
The UPS will begin its start-up process. After entering the Normal Mode, the UPS is
ready for operation.
Shutting down the UPS
Press the “Select-up” & “Select –down” button simultaneously for one second. The UPS will
turn off.
DC Start-up of the UPS
Step 1: Without connecting the UPS into any AC input power.
Step 2: Press the “Select-down” & “Enter” button simultaneously to switch on UPS. The UPS
will begin its start-up process. After entering the Battery Mode, the UPS is ready for
operation.
During shutdown, do not press any buttons. Pressing a button may
cause the UPS to re-energize and deliver output power.
