Switch-mode power supply AC2000 N1 / DC2000 N1 / AC3000 N1 / DC3000 N1 - Operating instructions
80001533 EFE en Page 20 of 41
Subject to change without notice.
1
Derating for AC3000 N1 and DC3000 N1: From 32 V / 100 A to 35 V / 91.5 A (3.2 kW)
( section 4.3.1)
2
with sinusoidal mains voltage
3
Depth from rear edge of front panel (without handles, plugs and controls)
4
Condensation not permitted, take derating into account ( section 4.3.2)
Type
AC2000 N1
E230 G24/65
BWrg-Cü
AC3000 N1
E230 G24/100
BWrg-Cü
DC2000 N1
G220 G26/65
Wrg-Cü
DC3000 N1
G220 G26/100
Wrg-Cü
DC undervoltage
response value
Adjustment range
≤ 24 V DC ± 2 %
18 to 30 V DC
Self-resetting warning without switch-
off (response delayed t 2 s)
≤ 22.8 V DC ± 2 %
18 to 30 V DC
Switch-off with latching (response
delayed t 2 s)
DC overvoltage
response value
Adjustment range
≥ 32.0 V DC ± 2 %
18 to 35 V DC
≥ 29 V DC ± 2 %
18 to 35 V DC
Switch-off with latching (response delay t 30 ms)
Overtemperature
warning
Warning via LED and collective fault relay
Overtemperature
shutdown
Self-resetting
switch-off
Shutdown with
self-holding
Self-resetting
switch-off
Mechanics and environment
Dimensions (mm)
(W x H x D)
3
483 x 177 x 206 mm
(19" x 4 U)
Weight 11 kg
Ambient temperature
during operation, at the
air inlet of the appliance
4
0 - 55 °C 0 - 45 °C 0 - 55 °C 0 - 45 °C
