4.2 Type overview: Technical data
Type AC2000 N1
E230 G24/65
BWrg-Cü
AC3000 N1
E230 G24/100
BWrg-Cü
DC2000 N1
G220 G26/65
Wrg-Cü
DC3000 N1
G220 G26/100
Wrg-Cü
Part number 10005614 10005616 10005613 10005615
Nominal input voltage 230 V AC ± 15 % 220 V DC + 35 % / - 15 %
Frequency 47 to 63 Hz DC
Current consumption in
nominal operation
8,1 A 12,4 A 8,1 A 12,5 A
Earth leakage current t.b.d. < 3,5 mA
Output voltage
Set value
Trickle charging (2.23
V/cell):
Charging (2.4 V/cell):
EPS (2.1 V/cell):
Ext. Adjust:
Adjustment range:
(for 12 cells)
26,8 V ± 1 %
28,8 V ± 1 %
25,2 V ± 1 %
31,3 V ± 1 %
17 to 35 V
(Reduction for diode test
in characteristic curve EPS)
26,0 V ± 1 %
26,0 V ± 1 %
24,4 V ± 1 %
26,0 V ± 1 %
17 to 35 V
Output current
Set value
Adjustment range
(take derating into
account)
1
65 A ± 2 %
10 to 65 A
100 A ± 2 %
10 to 100 A
65 A ± 2 %
10 to 65 A
100 A ± 2 %
10 to 100 A
Short-circuit current 1-fold (permanently short-circuit proof)
On request: 2-fold for ≥ 1 sec
2-fold for ≥ 1 sec,
then 1-fold (permanently short-circuit-
proof)
Voltage ripple and noise
(peak-to-peak)
< 0,5 %
Battery type 11-13 Pb cells ---
Power factor ≥ 0,99 ---
THDi at nominal load < 9% < 7 % ---
Efficiency typ. 94 %
Monitoring:
Mains undervoltage On: ≥ 190 V AC / Off: ≤ 180 V AC
± 5 %
2
On: ≥ 175 V DC / Off: ≤ 165 V DC
± 5 %
Mains overvoltage On: ≤ 265 V AC / Off: ≥ 275 V AC
± 5 %
2
On: ≤ 300 V DC / Off: ≥ 320 V DC
± 5 %
Mains transients Surge & Burst  see section 4.1 Surge & Burst  see section 4.1
In addition:
1.6 times the rated input voltage (3 s)
