Switch-mode power supply AC2000 N1 / DC2000 N1 / AC3000 N1 / DC3000 N1 - Operating instructions
80001533 EFE en Page 18 of 41
Collective fault relay ......................... Potential-free with safe isolation to the DC
output, contact load capacity:
max. 250 V AC / 8 A (resistive)
max. 60 V DC / 0.6 A DC
max. 24 V DC / 4 A DC
Version as gold-plated signal contact
Ext. analog setpoint specification..... No potential separation to DC output X2,
Ext. sensing line ............................... No electrical isolation to DC output X2,
Cables must be twisted or shielded
Ext. on/off ......................................... Floating to DC output X2,
connected to potential of remote signalling
Ext. characteristic switching ............. Potential-free to DC output X2,
connected to potential of remote signalling
Analog actual value output .............. Scaling to
- actual voltage value: 35 V = 20 mA or 10 V
- Actual current value: 100 A = 20 mA or 10 V
Accuracy:
- Actual voltage value: ± 2 % of nominal voltage
(for the setting range)
- Actual current value : ± 2 % of nominal current
(for 10 - 100 % nominal current)
Type of output:
0 - 20 mA
0 - 10 V (optionally via switchable 500 Ω load)
Remote supply not permitted!
Potential-free to DC output X2,
Connected to potential of remote signalling
LCD display ..................................... Accuracy ± 2 % in relation to the
nominal value
RoHS ............................................... Compliant with exception acc. to Art. 5 and 6
Note: Nominal values (rated voltage/rated current) depend on the type and are
listed in the following type overview.
