Switch-mode power supply AC2000 N1 / DC2000 N1 / AC3000 N1 / DC3000 N1 - Operating instructions
80001533 EFE en Page 28 of 41
A maximum of six devices can be arranged one above the other in a
cabinet. A distance of 134 mm (= 3 U) must be maintained between the
appliances. Air ducts must be installed between the appliances in such
a way that the supply air temperature of the individual appliances
corresponds to the permissible ambient temperature.
The maximum power loss per appliance is approx. 200 W (depending
on the type) and 90 % is generated in the rear part of the appliance.
ATTENTION!
Risk of damage and fire due to obstructed heat sinks and
ventilation openings.
Do not cover the heat sink and ventilation openings.
Do not bring highly flammable materials into contact with
the heat sink.
