AEG BE7900061M - Freestanding Installation: Anti-Tilt Brackets

28
Hook
C
L
Hole location for
hook installation
425mm
840mm
376
Measurements are to be adjusted to account for
the thickness of any skirting board or tiles coming
between the back of the appliance and the wall
194
INSTALLATION OF THE APPLIANCE (CONTINUED)
Freestanding installation (continued)
Installation of anti-tilt brackets and hook
• Theanti-tiltbracketsmustbesecuredtothefloorat
rear of cavity with an appropriate fastener according
to dimensions in diagram.
Wall
Appliance
Chain installed
• Thehookistobesecuredtothebackwallinthe
location shown above with an appropriate fastener
capable of withstanding a 10kg load.
• Connectservicestotheappliancepriortoplacing
into cavity.
• Tolocateappliance,slideintocavityandensuring
the rear left and right foot of appliance are captured
by the anti-tilt brackets.
• Beforetheapplianceisfullypushedintoposition,
place the chain attached to the rear of appliance
onto the wall hook.
