AEMC 5600 - Resistance on Electric Motors

Micro-Ohmmeter Model 5600
Measuring Resistance on Electric Motors
For this test, Kelvin probes should be used (Figure 8). Make contact with
each segment on the motor commutator. Allow approximately two
seconds for the display to stabilize.
C 2
P 2
C 1
P 1
Rx
MICRO-OHM
!
F1
– I
®
INSTRUMENTS
Figure 8
- 15 -
