AerAtron AE2+ Series - LED Light Kit; Ceiling Extension Kit

10
44
OPTION A
LED Light Kit
Line up the 2 pins on the LED light with the 2 Holes in the
Ceramic Holder and gently push the LED Light up ll the
Safety clip is engaged.
Re-check the correct assembly by gently pulling on the
Light to make sure the LED is ght.
OPTION B
Ceiling Extension Kit
“A”
150mm (6”)
“B”
26.6mm ROD
Suitable for Raked Ceiling up to 17
LED LIGHT
“B” Extension Rod Length
115mm Rod (4
17/32”
)
600mm Rod (23
5/8”
)
900mm Rod (35
7/16”
)
Accessories Required
Included
Not Included
Not Included
“A” Ceiling to Fan blade
420mm (16
17/32”
)
910mm (35
53/64”
)
1210mm (47
41/64”
)
