8
STEP 7
Attaching the Fan Motor Housing
Align the 3 tabs with the 3 holes on the
Housing and move upwards. Push tabs
inwards slightly before sliding upwards
unl you hear a click as the tabs lock.
STEP 8
Assembling the Fan Blades
A B
Place the Hub Upper onto a clean working area.
Line-up the two mounng holes in the Fan Blade
with the 2 holes in the Hub Upper.
To ensure ght and secure blade assembly a
power tool on low torque seng (4-6) can
be used.
Fix the 3 Fan Blades ght and firm using 2 Hub
screws for each Blade.
Connues next page
CLICK!
Constantly handle fan with care at all mes to
avoid damaging the fan/surface
!
To Next Page
