Aerco Benchmark 2.0 User Manual

APPENDIX F
(5)
PART OF GAS TRAIN ASSY.
(4) ONLY NEEDED ON DUAL FUEL
FOR PICTORAL PURPOSES ONLY,
FM GAS TRAIN (NON DUAL FUEL) IS SHOWN
-7 (150 PSI RELIEF VALVE SETTING)
-6 (60,75,100 & 125 PSI RELIEF VALVE SETTING)
-5 (30 AND 50 PSI RELIEF VALVE SETTING)
NOT SHOWN IN DRAWING
NOTES:
(3)
(2)
(1)
TWO (2) REQUIRED FOR DUAL FUEL BMK2.0 LN(6)
(6)
(7)
SEE DRAWING AP-A- FOR DUAL FUEL DETAILS
(2)
(1)
(1)
(5)(1)
(7)(5)
(1)
(1)(6)
(1)
(1)
(5)
(4)(1)
(4)(1)
(5)(4)(1)
(4)
(4)
(4)(1)
(4)(1)
(1)
(1)
(1)
CONTROLS
ITEM PART NO. QTY DESCRIPTION
30 123966 1 OVER TEMP SWITCH AUTO
31 123552 1 OVER TEMP SWITCH MANUAL
32 61002-5 1
BLOCKED INLET SWITCH
33 60011-2 1
BLOWER PROOF SWITCH
34 161560 1 I /O WIRING BOX
35 181197 1 C-MORE CONTROL BOX
36
GP-122464
1 IGNITION TRANSFORMER
37 33048 1 VFD MOUNTING BRACKET
39 61024 1 AIR TEMP SENSOR
41
GP- 122569
1 IGNITION CABLE ASSY.
42 63016-1 1 BMK2.0LN SHELL HARNESS
46 64059 1 120V POWER WIRING BOX
47 161450 1
BMK2.0LN GAS TRAIN WIRING
HARNESS
48 122843 1 LOW WATER CUT-OFF
49 123449 1 SHELL TEMP. SENSOR
50 161521 1
THERMOWELL, DUAL AQUASTAT BULB
51 61002-1 1
LOW GAS PRESSURE SWITCH
52
61002-12
1
HIGH GAS PRESSURE SWITCH
(NON DUAL FUEL)
DUAL FUEL HGPS - NAT. GAS
DUAL FUEL HGPS - PROPANE
53 65090 1
DRIVE REACTOR
54
55
OTHER ACCESORIES / PARTS
ITEM PART NO. QTY DESCRIPTION
56 69087 - 1 PRESS./TEMP. GAUGE
57
SEE SD-A-613
1 PRESSURE RELIEF VALVE
58 92006-7 1
EXT. MANUAL SHUT-OFF VALVE
59 91030 1 1" DRAIN HOSE, 60" LG
60 92006-7 1 1 1/2" NPT BALL VALVE
61 24060 1 COND. TRAP ASSEMBLY
62
OTHER DUAL FUEL COMPONENTS
ITEM PART NO. QTY DESCRIPTION
63 72031 1 "PROPANE" LABEL
64 72032 1 "NAT. GAS" LABEL
65 1
DOUBLE GAS TRAIN WIRING
HARNESS
66 65024 1 FUEL SELECTOR SWITCH
67 33036 1
FUEL SELECTOR SWITCH
MOUNTINGBRACKET
68 72030 1
FUEL SELECTOR SWITCH LABEL
69 1 DUAL FUEL WIRING HARNESS
70
SHEET METAL / PANEL ASSEMBLY
ITEM PART NO QTY DESCRIPTION
71 37024 1 LEFT REAR PANEL
72 37023 1 RIGHT REAR PANEL
73 49064 2 TOP RAIL
74 201233 1 MOUNTING PANEL
75 201113 1
FRONT PANEL
ENCLOSURE
76 201120 1 FRONT DOOR ASSY.
77
GP-122620
4HANDLE
78 37019 2 TOP PANEL
79 37002 4 SIDE PANEL
80 74002 1 BMK2.0LN LOGO
OTHER PARTS
ITEM PART NO QTY DESCRIPTION
81 99017 1
GAS PRESSURE SNUBBER -
PART OF GAS TRAIN
82
83
84
85
AERCO
INTERNATIONAL, INC.
NORTHVALE, NJ 07647
BENCHMARK 2.0 LOW NOx
BOILER PARTS LIST
D
PL - A - 158
(SHEET 2 OF 7)
DRAWN BY: SJD
DATE: 10/13/09
*NOT TO SCALE*
F-7

Aerco Benchmark 2.0 Specifications

General

Model	Benchmark 2.0
Category	Boiler
Fuel Type	Natural Gas or Propane
Type	Condensing
Input Capacity	2, 000, 000 BTU/h
NOx Emissions	<20 ppm
Operating Pressure	160 psi
Vent Diameter	6 inches
