(4) Flight Controller Installation
---> Direction of Nose
The FlightController can only be mounted as described above, horizontally and the arrow must
be pointed to the nose!
From NB ONE Reviews
• the unit needs to be mounted perfectly leveled with the plane as you cannot offset any
differences (there is no menu).
• the gyro can not be mounted in other position (side,etc), the reason is the same as
above; it is highly advisable to mount the gyro as close as possible to the COG of the
plane
• you need to connect ALL the input channels coming from the receiver even if you DO
NOT USE THEM, otherwise the unit will not engage; if you do not need the rudder for
example just disconnect the servo from the output.
This is also valid for the NB ONE+ FlightController !!
