AERMEC ANKI 045 - System Example: Heating; Cooling + Domestic Hot Water

15
SYSTEM EXAMPLE: HEATING / COOLING + DOMESTIC HOT WATER
Accessory
MOD485K
ANKI with integrated
pump (X version)
DHW storage tank
Cold/hot inertial storage tank
Radiant panel
for heating
Chronothermostat
Radiant panel
for heating
DHW DCW Water mains
Aermec FCZ series fancoil
Thermostat
Se chapter "3-WAY VALVE OPERATION FOR THE production of domestic hot water" page 19
