16 18.01. 6755441_03
ANL-ANLH 020-202
EN
3.8. ANL 020 ÷ 025 
868
900
354
310
Ø 9.52 L
Ø 15.88 G
196
83
143
650
330
Ø 9
895
122,50 122,50
Gx
Gy
holes for electrical
cables
gas
liquid
A
D
CB
Mod. A B C D
VT9 40 30 23 M8
WARNING
For the weight distribution refer to
versions "° | H"
AC
B
D
