MINIMUM AVERAGE WATER TEMPERATURE
Dry bulbe air temperature [°C]
21 23 25 27 29 31
15 3 3 3 3 3 3
Wet bulbe air temperature °C 17 3 3 3 3 3 3
19 3 3 3 3 3 3
21 6 5 4 3 3 3
23 - 8 7 6 5 5
Maximum water inlet temperature ............................ 80 °C
Maximum working pressure ....................................... 8 bar
Operating Voltage ..............................230V(±10%) ~ 50Hz
Room Temperature ................................................. 0÷45°C
Room Humidity .................................................<85% U.R.
To prevent the formation of condensation on the exterior of
the unit while the fan is operating, the average water
temperature should not drop beneath the limits shown in the
table below, determined by the thermo-hydrometric ambient
conditions.
These limits refer to unit operation with fan at minimum speed.
In case condensation is formed on the exterior of the unit
if cold water circulates through the coil while the fan is off
for prolonged periods of time, it is advisable to fit the
additional three-way valve.
Water flow limits (3-row coil ):
MOD. FCX 17 22 32 42 50 62 82 102
Minimum water flow [l/h] 100 100 100 150 150 300 300 300
Maximum water flow [l/h] 750 750 750 1100 1100 2200 2200 2200
OPERATING LIMITS
Water flow limits (1-row coil):
MOD. FCX 17 22 32 42 50 62 82 102
Minimum water flow [l/h] 50 50 50 50 50 100 100 100
Maximum water flow [l/h] 400 400 400 400 400 900 900 900
Water flow limits (4-row coil):
MOD. FCX 24 34 44 54 64 84
Minimum water flow [l/h] 150 150 150 150 300 300
Maximum water flow [l/h] 1100 1100 1100 1100 2200 2200
Minimum average water temperature
