AMP BRACKETS FOR HANGING UNITS
Kit includes brackets and bolts for ceiling
installation..
BC AUXILIARY CONDENSATE DRIP
TRAY
Made of thermoplastic material, collects
the condensate forming in summer
operation in the region of the non-
insulated hydraulic connections and
conveys it to the outside. In particular,
the BC4 drip tray must be used on all the
sizes with vertical installation of the unit.
Attention: The valve VCF and the
driptray BC4 can be installed at the
same time on the fan coil.
Attention: BC8 and BC9 are not
applicable to fan coils with cabinet case
The BC5 drip tray must be installed on
sizes FCX 17, 22, 32, 42, 50 and 24, 34,
44, 54 with horizontal installation.
The BC6 drip tray must be installed
on sizes 62, 82, 102 e 64, 84 with
horizontal installation.
The BC8 drip tray must be installed on
sizes FCX 17, 22, 32, 42, 50 and 24, 34,
44, 54 in version P - PE - PO - POE with
horizontal installation.
The BC9 drip tray must be installed on
sizesFCX 62, 82, 102 and 64, 84 in
version P - PE - PO - POE with horizontal
installation.
BV WATER HEATING COIL
The single-row heating coil can be
installed in four-tube fancoils above the
standard coil.Coil operation is regulated
by a control panel, that actuates a twin
valve
CHF VENTILCASSAFORMA
A galvanised template that makes it
possible to space to the house fan coils
in the wall (FCX P). The template will
make masonary work easy during the
construction of a niche where the fan
coils will be intalled. When work is
finished the fan coil will be completely
hidden from view.
DSC CONDENSATE DRAINAGE
DEVICE
A pump drains condensate from the
unit when natural runoff is not possible.
Installed on the exterior of the unit
GA INTAKE LOUVRE
Fixed slat sheet metal louvre with stoved
polyurethane powder paint finish. The
sub-frame is supplied as standard
GAF INTAKE LOUVRE WITH FRAME
AND FILTER
Fixed slat louvre with stoved
polyurethane powder paint finish; rear
side features frame for the filter. The sub-
frame and filter are supplied as standard.
GM DELIVERY LOUVRE
Louvre with high-resistance enamel
finish; comes with adjustable heat-
moulded plastic slats for air diffusion.
The subframe is supplied as standard.
MA HIGH COVER CABINET
Consisting of the cover cabinet, fixed
louver and air filter for fan coil in
vertical, floor-standing version. The
FCX for ceiling installation with the MA
cabinet assume the characteristics of the
FCX-AS and can only be fitted with the
accessories reserved for this model. BC8
and BC9 are not applicable to fan coils
with cabinet case.
MU UNIVERSAL COVER CABINET
Consisting of the cover cabinet, tiltable
(in sizes 17, 22, 32, 42 and 50) or
fixed louver (in sizes 62, 82 and 102)
and air filter for universal version fan
coil (FCX - U). The FCX for ceiling
installation with the MU cabinet assume
the characteristics of the FCX-US and
can only be fitted with the accessories
reserved for this model. BC8 and BC9
are not applicable to fan coils with
cabinet case..
PA INTAKE PLENUM
In galvanized steel, complete with
connections for circular section ducts of
diameter 200 mm.
There are two assembly positions for the
plenum, for intake parallel to the fan coil
or intake at 90°.
PA FRONT INTAKE PLENUM
In galvanized steel, complete with
connections for circular section ducts of
diameter 200 mm. The plenum can be
used with a front intake coupling parallel
to the fan coil delivery or, in sizes PA 32
- 42 - 62 F, also with lateral intake.
PC REAR COVER PANEL
Conveniently covers exposed rear fancoil
sections.
The panel is required by current safety
standards for units installed away from
the room wall.
PCR CONTROL PANEL COVER
Galvanised sheet metal cover designed
to protect unit controls and electrical
terminals of ducted installations with
electrical resistance.
PM DELIVERY PLENUM
Galvanised sheet metal plenum,
externally insulated, complete with
plastic delivery unions for circular
section ducting.
RD STRAIGHT CONNECTION FOR
AIR DELIVERY
Galvanised sheet metal used to convey
air in case of installation of vertical or
horizontal recessed fan coil.
RDA STRAIGHT CONNECTION FOR
AIR INTAKE
Galvanised sheet metal used to convey
intake air in case of installation of
vertical or horizontal recessed fan coil.
RP CONNECTION AT 90° FOR AIR
DELIVERY
Galvanised sheet metal used to convey
air in case of installation of vertical or
horizontal recessed fan coil.
RPA CONNECTION AT 90° FOR AIR
INTAKE
Galvanised sheet metal used to convey
intake air in case of installation of
vertical or horizontal recessed fan coil.
RX ELECTRIC RESISTANCE
Armoured electric resistance, complete
with safet thermostat. It is available as an
accessory for all versions.
SE FRESH AIR DAMPER
Foreseen for versions A, AS, ACB, ACT,
APC, P, PPC, PO and PE with skirting
and allows the changing of air in the
room. It is mounted at the base of the fan
coil, between the skirting. The manual
control is loacted on the right skirting.
SIT 3
Each fan coil has a SIT3 card that
becomes Slave and can be controlled
by a central control panel with
electromechanic selector or with SIT5.
Up to 10 fan coils can be applied with
SIT 3 and one central control unit. The
electronic control panels and those
equipped with valve controls must be
interfaced with a SIT 5. The electronic
control panels with speed control only
can be connected directlt to the SIT 3
without interface SIT 5.
SIT 5
The SIT 5 accessory, interface master
card Master, is connected to electronic
control panels or electromechanic
control panels with valave controls
and /or electric resistances. The SIT 5
interface card connected (up to 10) are
all equipped with interface Slave SIT3.
SW3 MINIMUM WATER TEMPERATURE
PROBE
The SW3 accessory is a probe for
detecting the water temperature of the
heating coil to prevent functioning when
the temperature is less than 39°C. The
SW3 probes are powered by a 230V
single phase voltage. The probes are
equipped with cables 2500mm long.
VCF 3 WAY VALVE KIT
The SW3 probe must be combined to
this accessory.
Kit complete with copper
connections and 3 way valves all
or nothing type, to be powered by a
230 V ~ 50Hz voltage supply.
They are available for fan coils :
- with 3 row coil 4 (VCF41, VCF42,
VCF43),
- with 4 row coil(VCF42, VCF43),
- with 1 row additional coil (BV) (VCF44,
VCF45).
* Attention: The VCF valve and the drip
tray BC4 can be installed at the same
time as the fan coil.
ZX5 - ZX6 SKIRTING FOR HIGH
CABINET
In plastic, mounted at the base of the
cabinet when the appliance is placed on
the floor.
ZX7 - ZX8 SKIRTING FOR WALL
VERSION
In galvanised steel, mounted at the base
of the cabinet when the appliance is
placed on the floor and recessed into the
wall.
ACCESSORIES
