42
E
nglish
A
CCESSORIES
2
2
2
BC4 DRIP
TRA
Y
BC5-6 DRIP
TRA
Y
DIMENSIONS
[mm]
Mod.
FCX 22÷50
FCX 62÷82
A
[mm] 109
126
DIMENSIONS
[mm]
Mod.
BC
5 BC
6
A
[mm]
375 476
B
[mm]
69 72
ø16
B
C
BC8-9 DRIP
TRA
Y FOR HORIZONT
ALL
Y INST
ALLA
TION
DIMENSIONS
[mm]
Mod.
BC
8 BC
9
A
[mm]
420 524
B
[mm]
146 146
C
[mm]
25 25
VCF valv
e and BC4
drip tr
ay can not be
contempor
ary instal-
led on the same fan
coil.
AMP SUPPORTS FOR
W
ALL/CEILING MOUNTING
VERSION
39
