English
USE
1 - LIQUID CRYSTAL DISPLAY
Indicates the working settings and the temperature.
2 - WORKING MODE
Allows you to select the working mode you prefer.
3 - TEMPERATURE adjustment
AND
Allow you to modify the temperature settings.
4 - FAN SPEED
Allows you to set the ventilation speed of the fan coil (low,
average, maximum, automatic)
5 - SWITCHING ON AND OFF
AND TEMPERATURE CONVERSION °C - °F
Allows you to switch the fan coil on and off.
With the thermostat switched off, by pressing the button for
about 12 seconds the visualisation of the temperature changes
from °C to °F and vice versa.
6 - TEMPERATURE PROBE
Reveals the room temperature.
7 - VISUALISATION OF TEMPERATURE SCALE °C - °F
Indicates the temperature scale being used - °C or °F.
DISPLAY
1 - TEMPERATURE VISUALISATION (C°)
- Temperature set.
- Room temperature (pressing the two keys
and
at the same time).
2 - VISUALISATION OF CONTINUOUS VENTILATION
3 - VISUALISATION OF THERMOSTAT-CONTROLLED
VENTILATION
4 - Visualisation of working mode
- Cooling
- Heating
- Automatic
- Ventilation Only
5 - VISUALISATION OF VENTILATION SPEED
- Low
- Average
- Maximum
- Automatic
6 - DISPLAY OF WATER TEMPERATURE NOT SUITABLE FOR
THE FUNCTIONING MODE / SENSOR ALARMS
1
2543
2
1
4
3
5
6
7
