AERMEC GLL10R User Manual

12
IFCLTY 1112 - 4528511_04
TECHNICAL DATA
FCL 2-pipe versions FCL 32 36 42 62 72 82 102 122
Heating
Heating capacity 50°C
Speed 4 W - - 4950 6250
6750 7100 10600 13000
Speed 3 W 2380 3750 3940 4780
5230 5700 8300 10500
Speed 2 W 1760 2690 3030 3830
4490 4850 7000 8800
Speed 1 W 1330 2050 2250 3050
3650 3500 4950 6300
Water fl ow rate
Speed 4 l/h - - 679 857
939 1032 1548 1892
Speed 3 l/h 327 516 559 678
705 824 1206 1539
Speed 2 l/h 253 387 437 552
576 697 1015 1290
Speed 1 l/h 200 308 337 458
481 482 697 922
Pressure drop (VL)
Speed 4 kPa - - 23 32
38 23 25 34
Speed 3 kPa 9 14 16 21
23 15 16 24
Speed 2 kPa 6 8 10 15
16 11 12 17
Speed 1 kPa 4 5 6 10
11 669
Cooling
Cooling capacity
Speed 4 W - - 3950 4980
5460 6000 9000 11000
Speed 3 W 1900 3000 3250 3940
4100 4790 7010 8950
Speed 2 W 1470 2250 2540 3210
3350 4050 5900 7500
Speed 1 W 1160 1790 1960 2660
2800 2800 4050 5360
Sensible Cooling
capacity
Speed 4 W - - 3160 3810
4100 4200 6660 8470
Speed 3 W 1520 2400 2360 2810
3000 3300 5140 6870
Speed 2 W 1250 1780 1820 2270
2350 2770 4300 5730
Speed 1 W 990 1390 1380 1860
1890 1900 2940 4040
Water fl ow rate
Speed 4 l/h - - 679 857
939 1032 1548 1892
Speed 3 l/h 327 516 559 678
705 824 1206 1539
Speed 2 l/h 253 387 437 552
576 697 1015 1290
Speed 1 l/h 200 308 337 458
481 482 697 922
Pressure drop (VL)
Speed 4 kPa - - 25 36
43 25 28 38
Speed 3 kPa 10 15 18 24
26 17 18 26
Speed 2 kPa 7 9 11 16
18 12 13 19
Speed 1 kPa 4 6 7 12
13 6710
Common data
Fans no. 1 1 1 1
1 111
Air fl ow rate
Speed 4 m3/h - - 700 880
900 1100 1350 1750
Speed 3 m3/h 600 600 530 660
680 830 1010 1350
Speed 2 m3/h 410 410 360 500
520 680 830 1100
Speed 1 m3/h 300 300 260 380
400 460 560 750
Sound power
Speed 4 dB(A) - - 53 61
63 50 54 60
Speed 3 dB(A) 46 46 46 54
56 45 48 54
Speed 2 dB(A) 38 38 38 47
49 43 45 50
Speed 1 dB(A) 35 35 35 41
43 39 40 44
 Sound pressure
Speed 4 dB(A - - 44 52
54 41 45 51
Speed 3 dB(A 37 37 37 45
47 36 39 45
Speed 2 dB(A 29 29 29 38
40 34 36 41
Speed 1 dB(A) 26 26 26 32
34 30 31 35
Input power
Speed 4 W - - 75 83
93 150 155 175
Speed 3 W 45 45 47 53
62 105 110 125
Speed 2 W 31 31 32 37
49 80 80 105
Speed 1 W 21 21 22 26
40 45 50 55
Input current (max speed) A 0.22 0.22 0.33 0.37
0,40 0.70 0.69 0.75
Peak current A 0.66 0.66 0.99 1.11
1,20 2.10 2.07 2.25
Power supply V / Hz 230 ~ 50Hz
Maximum protection level IP 20 20 20 20
20 20 20 20
Heat exchanger water content L 1.2 1.5 1.5 2.1
2,1 3 4.5 4.5
Plumbing connections Ø gas 3/4” 3/4” 3/4” 3/4”
3/4” 3/4” 3/4” 3/4”
Kvs (3-way valve, standard version) 2.5 2.5 2.5 2.5
2,5 444
Kvs (2-way valve, V2 version) 2.5 2.5 2.5 2.5
2,5 2.5 2.5 2.5
Performance values refer to the following conditions:
 Sound pressure measured in semi-reverberating chamber, 100m
3
,
and with reverberation time Tr = 0.5s
Cooling:
- room air temperature 27°C D.B. ; 19°C W.B.
- inlet water temperature 7°C ; maximum speed
- t water 5°C
Heating:
room air temperature 20°C
• water inlet temperature: 70°C ; t water 10°C
• water inlet temperature: 50°C ; maximum speed
- water flow rate as for cooling
= Performance certified EUROVENT 6/3 - Acoustic tests certified EUROVENT 8/2 (ISO 3741/2001)
