17
IFCLTY 1112 - 4528511_04
Tw
[°C]
T [°C]
Ta
W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
11
3
15 1010 1010 1262 1262 1506 1506 1744 1744 1982 1982 2101 2101
17 1379 1136 1428 1428 1536 1536 1748 1748 1987 1987 2105 2105
19 2144 1146 2139 1425 2135 1701 2137 1981 2182 2182 2208 2208
21 2947 1420 2941 1699 2934 1975 2928 2251 2925 2387
23 3806 1686 3797 1964 3790 2242 3784 2379
5
15 825 825 1105 1105 1368 1368 1622 1622 1869 1869 1991 1991
17 949 915 1151 1151 1370 1370 1624 1624 1873 1873 1995 1995
19 1692 946 1697 1226 1748 1521 1845 1828 1972 1972 2043 2043
21 2569 1254 2565 1532 2565 1810 2565 2087 2577 2230
23 3453 1532 3453 1813 3441 2087 3441 2226
7
15 483 483 868 868 1177 1177 1454 1454 1718 1718 1847 1847
17 484 484 872 872 1179 1179 1458 1458 1723 1723 1849 1849
19 799 564 1104 952 1334 1306 1546 1546 1755 1755 1862 1862
21 1997 1014 2002 1293 2062 1591 2156 1900 2212 2054
23 3016 1349 3012 1627 3009 1903 3003 2038
13
3
15 752 752 1009 1009 1258 1258 1499 1499 1738 1738 1856 1856
17 812 812 1012 1012 1261 1261 1501 1501 1742 1742 1860 1860
19 1478 853 1473 1128 1510 1415 1598 1598 1746 1746 1864 1864
21 2294 1137 2290 1414 2285 1687 2281 1961 2292 2103
23 3153 1406 3150 1684 3141 1958 3137 2095
5
15 511 511 833 833 1108 1108 1368 1368 1619 1619 1744 1744
17 513 513 834 834 1110 1110 1370 1370 1624 1624 1748 1748
19 803 568 1007 912 1203 1203 1398 1398 1626 1626 1750 1750
21 1830 946 1830 1222 1869 1509 1950 1811 1997 1961
23 2753 1243 2747 1518 2741 1791 2741 1929
7
15 244 244 487 487 887 887 1186 1186 1460 1460 1592 1592
17 244 244 487 487 887 887 1190 1190 1463 1463 1594 1594
19 251 251 489 489 898 898 1192 1192 1465 1465 1598 1598
21 928 590 1190 953 1409 1297 1611 1611 1705 1705
23 2174 1017 2174 1292 2217 1582 2251 1731
15
3
15 481 481 753 753 1007 1007 1253 1253 1493 1493 1613 1613
17 482 482 754 754 1009 1009 1256 1256 1497 1497 1615 1615
19 702 527 849 842 1027 1027 1259 1259 1499 1499 1619 1619
21 1581 846 1576 1117 1602 1400 1673 1673 1723 1723
23 2455 1126 2453 1400 2444 1671 2442 1807
5
15 195 195 528 528 839 839 1110 1110 1368 1368 1495 1495
17 196 196 528 528 840 840 1113 1113 1370 1370 1497 1497
19 197 197 533 533 842 842 1115 1115 1375 1375 1499 1499
21 881 573 1070 906 1254 1234 1439 1439 1534 1534
23 1967 940 1967 1212 1991 1494 2021 1640
7
15 39 39 244 244 507 507 900 900 1194 1194 1332 1332
17 39 39 244 244 507 507 902 902 1196 1196 1334 1334
19 39 39 244 244 509 509 904 904 1198 1198 1336 1336
21 253 253 524 524 930 930 1209 1209 1340 1340
23 1044 604 1284 952 1491 1287 1589 1452
COOLING CAPACITY - FCL36
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [w] = Total Cooling capacity
Ps [w] = Sensible Cooling capacity
Qv [m
3
/h] = Air flow rate
NB: the output values in bold type indicate the nominal value.
If sensible output values are above the total output, this means that
cooling is carried out without dehumidification.
If this occurs, take into consideration only the sensible output values.
The Cooling capacity of the table are at maximum speed (maximum
air flow). To determine the Cooling capacity based on the speed
(air flow), the values shown in the table must be multiplied by the
following factors (k):
FCL36
Qv [m
3
/h] k (Pc) k (Ps)
Speed V3
600 11
Speed V2
410 0,75 0,74
Speed V1 (Minimum)
300 0,60 0,58
COOLING CAPACITY CORRECTION FACTORS
