16
IFCLTY 1112 - 4528511_04
COOLING CAPACITY - FCL36
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B.[°C] = Inlet air temperature with dry bulb
Pc [w] = Total Cooling capacity
Ps [w] = Sensible Cooling capacity
Qv [m
3
/h] = Air flow rate
NB: the output values in bold type indicate the nominal value.
If sensible output values are above the total output, this means that
cooling is carried out without dehumidification.
If this occurs, take into consideration only the sensible output values.
The Cooling capacity of the table are at maximum speed (maximum
air flow). To determine the Cooling capacity based on the speed
(air flow), the values shown in the table must be multiplied by the
following factors (k):
FCL36
Qv [m
3
/h] k (Pc) k (Ps)
Speed V3
600 11
Speed V2
410 0,75 0,74
Speed V1 (Minimum)
300 0,60 0,58
Tw
[°C]
T [°C]
Ta
W.B.
[°C]
Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W] Pc [W] Ps [W]
21°C Ta D.B. 23°C Ta D.B. 25°C Ta D.B. 27°C Ta D.B. 29°C Ta D.B. 30°C Ta D.B.
5
3
15 2410 2022 2399 2300 2410 2410 2485 2485 2719 2719 2838 2838
17 3109 2011 3103 2296 3097 2575 3091 2854 3081 3081 3084 3084
19 3865 1995 3856 2280 3847 2562 3837 2842 3828 3118 3822 3256
21 4665 2258 4653 2541 4640 2821 4628 3100 4625 3240
23 5521 2513 5515 2799 5496 3076 5490 3216
5
15 2079 1838 2126 2126 2217 2217 2371 2371 2610 2610 2728 2728
17 2819 1854 2813 2137 2803 2415 2816 2701 2847 2847 2878 2878
19 3584 1845 3578 2131 3572 2413 3565 2695 3559 2972 3547 3107
21 4397 2116 4384 2398 4378 2681 4368 2961 4365 3100
23 5265 2378 5253 2660 5240 2940 5234 3080
7
15 1667 1601 1821 1821 1991 1991 2221 2221 2470 2470 2595 2595
17 2397 1634 2393 1916 2431 2211 2509 2509 2612 2612 2681 2681
19 3247 1672 3241 1956 3234 2237 3222 2514 3228 2796 3234 2939
21 4084 1957 4072 2237 4065 2519 4059 2799 4053 2936
23 4965 2226 4959 2510 4946 2790 4940 2929
7
3
15 1871 1727 1897 1897 2000 2000 2238 2238 2474 2474 2590 2590
17 2575 1726 2569 2008 2560 2286 2558 2558 2603 2603 2638 2638
19 3328 1714 3322 1998 3316 2280 3303 2555 3300 2833 3291 2968
21 4128 1980 4115 2261 3303 2555 4097 2819 4094 2958
23 4984 2238 4978 2521 4965 2801 4959 2940
5
15 1544 1538 1680 1680 1875 1875 2122 2122 2365 2365 2483 2483
17 2238 1554 2229 1833 2260 2123 2324 2324 2423 2423 2504 2504
19 3019 1558 3012 1842 3009 2123
3000 2400
2997 2678 3003 2821
21 3834 1834 3828 2117 3822 2397 3809 2673 3806 2812
23 4703 2099 4697 2381 4684 2660 4678 2799
7
15 1203 1203 1448 1448 1710 1710 1970 1970 2221 2221 2345 2345
17 1688 1283 1787 1602 1916 1916 2064 2064 2238 2238 2350 2350
19 2595 1354 2595 1638 2586 1915 2612 2206 2672 2506 2706 2656
21 3478 1663 3472 1944 3466 2223 3459 2501 3459 2641
23 4372 1941 4365 2223 4353 2500 4353 2641
9
3
15 1362 1362 1510 1510 1752 1752 1991 1991 2227 2227 2345 2345
17 2002 1436 1993 1714 2013 1998 2075 2075 2234 2234 2350 2350
19 2759 1433 2753 1715 2747 1994 2739 2269 2732 2545 2736 2686
21 3556 1700 3547 1981 3541 2260 3534 2538 3528 2674
23 4415 1963 4406 2243 4397 2522 4390 2660
5
15 1119 1119 1366 1366 1622 1622 1873 1873 2118 2118 2238 2238
17 1572 1228 1641 1531 1753 1753 1905 1905 2122 2122 2242 2242
19 2401 1264 2397 1544 2393 1823 2406 2107 2453 2399 2487 2487
21 3228 1547 3222 1828 3216 2105 3209 2382 3206 2519
23 4103 1818 4097 2098 4084 2375 4084 2516
7
15 846 846 1166 1166 1448 1448 1714 1714 1972 1972 2096 2096
17 1018 945 1263 1263 1491 1491 1718 1718 1976 1976 2101 2101
19 1830 1006 1843 1290 1916 1595 2028 1913 2161 2161 2234 2234
21 2803 1356 2797 1634 2797 1913 2803 2194 2822 2341
23 3728 1651 3722 1930 3715 2208 3709 2344
COOLING CAPACITY CORRECTION FACTORS
