AERMEC NRL 800 - 10 Distribution of Percentage Weights on; Supportingpoints

14
Aermec cod. INRLLSIY 13_01. 4086991_00
NRL 800 - 1800
GB
 DISTRIBUTION OF PERCENTAGE WEIGHTS ON SUPPORTINGPOINTS
1
2
7
8
G
Gx
Gy
4
3
5
6
TOP VIEW
MODEL
Version
Hydronic kit
EMPTY RUNNING KIT AVX
WEIGHT CENTRE OF GRAVITY TOTAL
WEIGHT
WATER
CENTRE OF GRAVITY
Lbs XG mm XG in YG mm YG in Lbs XG mm XG in YG mm YG in
NRL
800
A
00 4134 1296 51,02 954 37,55 4167 33 1298 51,09 955 37,61 AVX 704
01 4861 1289 50,75 1066 41,98 6504 1642 1280 50,41 1223 48,17 AVX 705
02 4971 1288 50,72 1081 42,55 6614 1642 1280 50,39 1232 48,49 AVX 705
03 4883 1289 50,75 1068 42,07 6526 1642 1280 50,41 1225 48,22 AVX 705
04 5016 1288 50,71 1085 42,72 6658 1642 1280 50,39 1234 48,59 AVX 705
P1 4475 1292 50,88 1012 39,82 4696 220 1292 50,88 1040 40,94 AVX 706
P2 4586 1291 50,84 1029 40,50 4806 220 1291 50,84 1056 41,56 AVX 706
P3 4497 1292 50,88 1014 39,93 4718 220 1292 50,87 1042 41,04 AVX 706
P4 4586 1291 50,85 1027 40,45 4806 220 1291 50,84 1055 41,52 AVX 706
NRL
900
A
00 4475 1344 52,90 927 36,51 4519 44 1345 52,96 929 36,59 AVX 710
01 5203 1330 52,38 1036 40,78 6856 1653 1313 51,68 1192 46,94 AVX 711
02 5313 1329 52,31 1050 41,35 6967 1653 1312 51,64 1201 47,27 AVX 711
03 5269 1330 52,35 1043 41,08 6923 1653 1312 51,66 1197 47,12 AVX 711
04 5445 1327 52,24 1064 41,91 7099 1653 1311 51,60 1209 47,60 AVX 711
P1 4817 1337 52,63 983 38,69 5049 231 1335 52,56 1011 39,79 AVX 706
P2 4927 1335 52,56 999 39,35 5159 231 1333 52,49 1026 40,39 AVX 706
P3 4883 1336 52,59 991 39,03 5115 231 1334 52,52 1019 40,11 AVX 706
P4 5016 1334 52,51 1010 39,76 5247 231 1332 52,44 1036 40,77 AVX 706
NRL
1000
A
00 4850 1330 52,34 933 36,75 4916 66 1332 52,42 936 36,85 AVX 716
01 5600 1319 51,93 1034 40,69 7275 1676 1305 51,39 1182 46,54 AVX 711
02 5710 1318 51,88 1047 41,22 7385 1676 1304 51,36 1190 46,86 AVX 711
03 5644 1318 51,91 1041 40,97 7319 1676 1305 51,37 1186 46,71 AVX 711
04 5820 1316 51,82 1060 41,74 7496 1676 1304 51,32 1198 47,18 AVX 711
P1 5214 1324 52,14 984 38,75 5467 254 1324 52,11 1011 39,79 AVX 712
P2 5324 1323 52,07 1000 39,36 5578 254 1322 52,05 1025 40,35 AVX 712
P3 5258 1323 52,10 992 39,07 5512 254 1323 52,08 1018 40,08 AVX 712
P4 5390 1322 52,03 1009 39,74 5644 254 1321 52,01 1034 40,70 AVX 712
VERSION COOLING ONLY
