1. Compressor
2. Plateheatexchanger
3. Thermostacexpansionvalve
4. Filterdrier
5. Solenoidvalve
6. Hotgasinjeconvalve
7. Safetyvalve
8. Unidireconalvalveonlyforversions
(02-04/P2-P4)
9. Liquidsightglass
10. Desuperheater(oponal)
11. Waterfilter
12. Pump(s)(oponal)
13.
Expansiontank(standardwithhydronicmodule)
14. Buffertank(optional)
15.
Flowswitch
16. Gauge
17. Airvent
18. Finnedcondensercoil
19. Fanassembly
20. Electricalpanel
21. MODU_CONTROLinterface

2
3
4
5
6
7
1
10
11
17
18
19
20
21
12
13
14
15
16
8
9
