2-76 Subject to Export Control, see Cover Page for details.
L. Flex Assy (62A1A2A6)
DESCRIPTION
This procedure covers: Remove. Install.
PRELIMINARY PROCEDURES
Remove Battery (para 2-4A).
Open Case Assy (para 2-4C).
Remove LCD Assy (62A1A2A4) (para 2-4H).
REMOVE
1. Remove cover from REMOTE Connector.
2. Remove two screws.
3. Remove Flex Assy.
INSTALL
1. Install Flex Assy.
2. Install two screws (6 in/lbs.).
3. Install cover on REMOTE Connector.
FOLLOW-ON MAINTENANCE
Install LCD Assy (62A1A2A4) (para 2-4H).
Close Case Assy (para 2-4C).
Install Battery (para 2-4A).
END OF TASK
062M-12
