B-6. COMM BREAKOUT BOX - RS-232 CONNECTOR PIN-OUT TABLE
1
6
5
9
PIN NO. SIGNAL NAME
1 NOT USED
2TX
3RX
4 NOT USED
5GND
6 NOT USED
7CTS
8RTS
9 NOT USED
Table B-8. Comm Breakout Box - RS-232 Connector Pin-Out Table
