Aeroflex 3500A - R F D I G I T I Z E R P C B a S S y

Subject to Export Control, see Cover Page for details. 2-65
F. RF Digitizer PCB Assy (62A1A2A2)
DESCRIPTION
This procedure covers: Remove. Install.
PRELIMINARY PROCEDURES
Remove Battery (para 2-4A).
Open Case Assy (para 2-4C).
REMOVE
1. Remove two coaxial cables.
2. Remove four nuts and four lock washers.
3. Remove the RF Digitizer PCB Assy.
INSTALL
1. Install the RF Digitizer PCB Assy.
2. Install four lock washers and four nuts (3 in/lbs.).
