2-78 Subject to Export Control, see Cover Page for details.
M. Audio I/O PCB Assy (62A1A2A7) (3500A Only) (cont)
INSTALL
1. Install Audio I/O PCB Assy.
2. Install two screws and washers (6 in/lbs.).
3. Solder three connectors to Audio I/O PCB Assy.
4. Connect wire cable connector.
5. Connect wire/ribbon cable and three ribbon
cables.
FOLLOW-ON MAINTENANCE
Close Case Assy (para 2-4C).
Install Battery (para 2-4A).
END OF TASK
