A-14 Subject to Export Control, see Cover Page for details.
CHASSIS ASSY (3500A)
64603 (7005-6244-400) ASSY, CHASSIS
REFERENCE PART CAGE
DESIGNATOR NUMBER CODE DESCRIPTION
1 9850 (1403-6253-700) 51190 CHASSIS,FRONT
2 9516 (1400-6255-300) 51190 BRACKET,DISPLAY
3 10623 (1414-6255-200) 51190 COVER,DISPLAY
4 33903 (2508-6255-400) 51190 SHIELD,DISPLAY
5 46697 (3900-5650-500) 51190 LENS,DISPLAY
6 36283 (2840-0026-000) 51190 WASHER,NYL,0.5310D,0.375ID,0.020T
7 35569 (2803-0188-003) 51190 SCREW,4-40 X 3/16 PFHM
8 35571 (2803-0188-006) 51190 SCREW,4-40 X 3/16 PPHM
9 37932 (2850-7866-300) 51190 STANDOFF,HEX,MALE-FEMALE
10 35600 (2803-0375-006) 51190 SCREW, 4-40 X 3/8 PPHM
11 35536 (2801-0375-006) 51190 SCREW,2-56 X 3/8 PPHM
12 35844 (2818-0000-017) 51190 STANDOFF,.188 HEX M/F,.187LG
13 37773 (2850-0000-012) 51190 NUT,HEX,SMALL PAT,2-56
14 36239 (2840-0000-004) 51190 WASHER,LOCK,INT TOOTH,2
A1 66010 (7010-6233-700) 51190 PCB ASSY,KEYPAD
A2 66002 (7010-6231-100) 51190 PCB ASSY,RF DIGITIZER
A3 66007 (7010-6233-200) 51190 PCB ASSY,MULTIFUNCTION
A4 67364 (7110-5600-000) 51190 PURCHASED ASSY,LCD
A5 67375 (7110-6200-300) 51190 PURCH ASSY,KEYPAD
A6 67377 (7110-6231-300) 51190 PURCH ASSY,FLEX
A7 66008 (7010-6233-500) 51190 PCB ASSY,HITS AUDIO I/O
J5 20338 (2113-0000-020) 51190 CONN UG1094/U
J6 20338 (2113-0000-020) 51190 CONN UG1094/U
J7 20338 (2113-0000-020) 51190 CONN UG1094/U
JTB1 21440 (2132-0004-000) 51190 CONN,JUMPER BLOCK,.1C,.025 PIN
64603 (7005-6244-400) ASSY, CHASSIS A0
Contains all parts shown in original with the following exception:
REFERENCE PART CAGE
DESIGNATOR NUMBER CODE DESCRIPTION
A4 67376 (7110-6200-400) 51190 PURCHASED ASSY,LCD
64603 (7005-6244-400) ASSY, CHASSIS A1
Contains all parts shown in Revision A0 with the following exception:
REFERENCE PART CAGE
DESIGNATOR NUMBER CODE DESCRIPTION
A3 66017 (7010-6235-600) 51190 PCB ASSY,MULTIFUNCTION
