Aeroflex 3500A - Page 157

CAUTION:
CONTAINS PARTS AND ASSEMBLIES
SUSCEPTIBLE TO DAMAGE BY
ELECTROSTATIC DISCHARGE (ESD).
3500A-31
A2A2
A2A4
A2JTB1
A2A3
A2A5
A2A6
A2J5
A2J6
A2J7
(A1J1/A3J11)
A2A3J11
A2A1
(A2A4W2P1/A2A3J2)
(A2A4W1P1/A2A7J1)
(A2A6P1/A2A3J4)
A2A7
A2A4W2P1
A2A4W1P1
3500A
Figure E-3. Chassis Assy (Sheet 2 of 2)
(64603-A1) (7005-6244-400) (62A1A2)
Subject to Export Control, see Cover Page for details. E-9
