G. Verification Data Sheets
GENERATOR VERIFICATION
T/R Connector
FREQUENCY
(MHz)
POWER METER
(dBm)
EXPECTED
(dBm)
ERROR
(Power Meter - Expected)
2 -50
20 -50
100 -50
200 -50
300 -50
400 -50
500 -50
600 -50
700 -50
800 -50
900 -50
1000 -50
ANT Connector
FREQUENCY
(MHz)
POWER METER
(dBm)
EXPECTED
(dBm)
ERROR
(Power Meter - Expected)
2 -30
20 -30
100 -30
200 -30
300 -30
400 -30
500 -30
600 -30
700 -30
800 -30
900 -30
1000 -30
