AES 7788 Series RF Subscriber Unit ─ Installation and Operation Manual
AES Corporation 2 40-7788, Rev 6, August 30, 2016
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING
JURISDICTION, AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply
with the requirements in the Standard for Control Units and Accessories for Fire Alarm
Systems, UL 864, certain programming features or options must be limited to specific values or
not used at all as indicated below.
Program Permitted in Possible functional
Group Feature or Option UL 864 (Y/N) settings Settings permitted in UL 864
Timing Parameters
AC Fail Report Delay Y 0-60 Min or Random R (Random) or 0-60 (Minutes)
Reporting Delay Y 0 – 80 Seconds 10 – 20 Seconds
Zone Programming
Fire/Trouble PKT Y Y or N Y
Zone Programming Y S, F or B If zone is in use F
If not in use B
Restoral Y X or R R
Set Modes
Enable Repeating Y Y or N Y
Suppress AC Fail N Y or N N
By Remote programming only
Acknowledge Delay * Y 60 – 330 Seconds Not greater than 60 Seconds
* Acknowledge delay is used in detecting the existence of a functional antenna and therefore affects antenna cut detection.
Note: UL and NFPA do not allow remote programming of an installed 7788F unless an
authorized person is present at the unit to temporarily enable this capability. Selecting
“Y” for Fire/Trouble PKT in Zone Programming function disables remote programming.
Entering one of the programming modes accessed with a directly attached programmer by
<Ctrl> <F1>, <Ctrl> <F2> or <Ctrl> <F3> enables remote programming for 10 minutes.
