AES 7788 Series RF Subscriber Unit ─ Installation and Operation Manual
AES Corporation 32 40-7788, Rev 6, August 30, 2016
To start, press programmer keys <CTRL>+<F3> (hold down the Control and the F3
keys at the same time). The following message appears:
FIRE/ ----OLD:NEW
TROUBLE PKT- N: . [Y/N] (N = existing data)
The sequence first asks if "Fire Trouble Packets" are to be sent. Answer Y/yes if you
wish to have the 7788F report "Zone Trouble" conditions. Otherwise answer N/no.
The existing programming is shown under the "OLD: " column. If you wish to
change the setting, enter Y or N. To leave unchanged, simply push <ENTER>.
Based on your response to this first parameter the available options for Set Zone
programming will vary.
Note: Answering “Y” to this question disables remote programming from
central station software. See Section 4.1.
After pressing <ENTER>, the following appears:
ZONE BANK 0 .
SET ZONE (BSF) B0 (available options)
OLD SSSSSSSS LOW>HI (S, F or B = existing data)
NEW ........ (Must enter exactly 8 values)
The available and valid Zone programming options are shown in the parentheses on
the display as shown above. The options that appear are determined by your input to
the "Fire/Trouble PKT" question above. The current programming is shown next to
the word OLD, Zones 1-8 in order left to right. Your new entries will appear directly
below next to the word NEW. You must enter a valid letter for each of the 8 zones.
Zones programming 1-8 can be set for: Entering more or less than 8 characters will
result in repeating the above response.
B - Bypassed
S - Supervised/E.O.L. (alarm on open or short);
F - Fire Supervised E.O.L. (alarm on short, trouble on open) Required for UL Fire
After successfully entering Set Zone data, the following appears:
SET RESTORAL (XR)B0 (available options)
OLD RRRRRRRR LOW>HI (R or X = existing data)
NEW .... (Must enter exactly 8 values)
The option to select individual zones to report returning to a normal state is available.
X = Restore Not Reported; R = Restore Reported. The existing or OLD
programming is shown for each zone. Your new entries will appear directly below
next to the word NEW. You must enter a valid letter X or R for each zone. Entering
more or less than 8 characters will result in repeating the above response.
When restore data entry is complete, Press <ENTER>. If data has been entered correctly,
the following message appears:
OK The zones are now programmed
Programming must be completed within 65 seconds or function will:
TIMEOUT
