Initial Setup
With the AC cord disconnected, remove the Mimas top cover by first removing the two Philips screws
on the rear panel closest to the top, then lift each rear corner one at a time.
Install 2 tubes into the Mimas. See Mimas Tube Guide. Afterwards replace the top cover and secure it with the
same 2 Philips screws.
Connect all sources to the Mimas rear panel inputs.
If used, connect a trigger cable to the device that the Mimas standby will either control, or be controlled by.
Connect a third party IR extender, if desired.
Connect the speakers to the Mimas outputs. Please adhere to all warnings and references in this documentation
with regards to not connecting the Mimas speaker minus (-) terminal to any ground.
Connect the AC cord.
Turn on the rear panel power switch. Each time the rear panel power switch is turned on, the Mimas will go into
Warm Up mode for up to 2 minutes. The timing of this is dependent on the current temperature of the Output
module heatsinks. During this time the display will read WARM UP.
Note: If using the optional HRC-3 hand held remote, it is shipped in “Transport” mode (off). It must first be set to
Active. Please refer to the Metis remote owner’s manual.
Install battery(s) in the hand held remote control.
CAUTION! To avoid loud pops and possible speaker damage, turn on all other system components
before taking the Mimas out of standby.
Standby
After the Mimas completes its Warm up phase, it will then go into Standby and the Standby LED will illuminate.
Pressing the STANDBY button will initiate the startup process. At this time the blue Standby LED will blink for a
few minutes before displaying the Main Menu.
