Verbose Structure Details
Header Units / Format Example Data Description
Red ATN1
Attenuation units
(Decimal number)
11.366656
Calculated attenuation of red wavelength for sample
spot sense1 in attenuation units. Calculated in
SingleSpot™ and DualSpot® sampling modes.
Red ATN2
Attenuation units
(Decimal number)
6.714724
Calculated attenuation of red wavelength for sample
spot sense2 in attenuation units. Calculated in
DualSpot® sampling mode.
Red K
Unitless
(Decimal number)
-0.00194589456077665
Calculated loading compensation factor for red
wavelength using sample spots sense1 and sense2,
used to compensate BC1 value resulting in BCc.
Calculated in DualSpot® sampling mode.
IR Sen1
Counts
(Whole number)
657342
Measured optical intensity of infrared (IR)
wavelength for sample spot sense1 in counts.
Measured in SingleSpot™ and DualSpot® sampling
modes.
IR Sen2
Counts
(Whole number)
792594
Measured optical intensity of infrared (IR)
wavelength for sample spot sense2 in counts.
Measured in DualSpot® sampling mode.
IR Ref
Counts
(Whole number)
976403
Measured optical intensity of infrared (IR)
wavelength for reference spot in counts. Measured
in SingleSpot™ and DualSpot® sampling modes.
IR ATN1
Attenuation units
(Decimal number)
8.610901
Calculated attenuation of infrared (IR) wavelength for
sample spot sense1 in attenuation units. Calculated
in SingleSpot™ and DualSpot® sampling modes.
IR ATN2
Attenuation units
(Decimal number)
5.190925
Calculated attenuation of infrared (IR) wavelength for
sample spot sense2 in attenuation units. Calculated
in DualSpot® sampling mode.
IR K
Unitless
(Decimal number)
-0.00266132899560034
Calculated loading compensation factor for infrared
(IR) wavelength using sample spots sense1 and
sense2, used to compensate BC1 value resulting in
BCc. Calculated in DualSpot® sampling mode.
UV BC1
Nanograms per
cubic meter (ng/m
3
)
(Integer)
23201
Calculated mass concentration for ultraviolet (UV)
wavelength for sample spot sense1 in nanograms
per cubic meter. Calculated in SingleSpot™ and
DualSpot® sampling modes.
UV BC2
Nanograms per
cubic meter (ng/m
3
)
(Integer)
24101
Calculated mass concentration for ultraviolet (UV)
wavelength for sample spot sense2 in nanograms
per cubic meter. Calculated in DualSpot® sampling
mode.
UV BCc
Nanograms per
cubic meter (ng/m
3
)
(Integer)
25613
Calculated mass concentration with DualSpot®
loading compensation for ultraviolet (UV)
wavelength using sample spots sense1 and sense2
in nanograms per cubic meter. Calculated in
DualSpot® sampling mode.
Blue BC1
Nanograms per
cubic meter (ng/m
3
)
(Integer)
24325
Calculated mass concentration for blue wavelength
for sample spot sense1 in nanograms per cubic
meter. Calculated in SingleSpot™ and DualSpot®
sampling modes.
Blue BC2
Nanograms per
cubic meter (ng/m
3
)
(Integer)
24635
Calculated mass concentration for blue wavelength
for sample spot sense2 in nanograms per cubic
meter. Calculated in DualSpot® sampling mode.
Blue BCc
Nanograms per
cubic meter (ng/m
3
)
(Integer)
25111
Calculated mass concentration with DualSpot®
loading compensation for blue wavelength using
sample spots sense1 and sense2 in nanograms
per cubic meter. Calculated in DualSpot® sampling
mode.
Verbose Structure Details
Header Units / Format Example Data Description
Green BC1
Nanograms per
cubic meter (ng/m
3
)
(Integer)
24088
Calculated mass concentration for green wavelength
for sample spot sense1 in nanograms per cubic
meter. Calculated in SingleSpot™ and DualSpot®
sampling modes.
Green BC2
Nanograms per
cubic meter (ng/m
3
)
(Integer)
24259
Calculated mass concentration for green wavelength
for sample spot sense2 in nanograms per cubic
meter. Calculated in DualSpot® sampling mode.
Green BCc
Nanograms per
cubic meter (ng/m
3
)
(Integer)
24509
Calculated mass concentration with DualSpot®
loading compensation for green wavelength using
sample spots sense1 and sense2 in nanograms
per cubic meter. Calculated in DualSpot® sampling
mode.
Red BC1
Nanograms per
cubic meter (ng/m
3
)
(Integer)
24137
Calculated mass concentration for red wavelength
for sample spot sense1 in nanograms per cubic
meter. Calculated in SingleSpot™ and DualSpot®
sampling modes.
Red BC2
Nanograms per
cubic meter (ng/m
3
)
(Integer)
23923
Calculated mass concentration for red wavelength
for sample spot sense2 in nanograms per cubic
meter. Calculated in DualSpot® sampling mode.
Red BCc
Nanograms per
cubic meter (ng/m
3
)
(Integer)
23615
Calculated mass concentration with DualSpot®
loading compensation for red wavelength using
sample spots sense1 and sense2 in nanograms
per cubic meter. Calculated in DualSpot® sampling
mode.
IR BC1
Nanograms per
cubic meter (ng/m
3
)
(Integer)
23958
Calculated mass concentration for infrared (IR)
wavelength for sample spot sense1 in nanograms
per cubic meter. Calculated in SingleSpot™ and
DualSpot® sampling modes.
IR BC2
Nanograms per
cubic meter (ng/m
3
)
(Integer)
23745
Calculated mass concentration for infrared (IR)
wavelength for sample spot sense2 in nanograms
per cubic meter. Calculated in DualSpot® sampling
mode.
IR BCc
Nanograms per
cubic meter (ng/m
3
)
(Integer)
23422
Calculated mass concentration with DualSpot®
loading compensation for infrared (IR) wavelength
using sample spots sense1 and sense2 in
nanograms per cubic meter. Calculated in
DualSpot® sampling mode.
CKSUM
Alphanumeric
(XXXX)
434B
