3.
Carefully lay the assembly
sheet over the side beams.
The top side of the sheet is the
HP2 profile SUN direction is
UP.
4.
Peel back the protection film
from the edges.
Insert the back end of the
sheet into the top-beam
assembly, between the Top-
Beam Cover and the top-
beam.
5.
Tighten screws in their
designated locations, along
the side beams. Work from
the back towards the front.
Note: Don`t over tighten,
leave sheet free.
6.
After tightening all the screws,
remove the Hex socket
button screw.
Tighten the cover to the top-
beam from the inside with
tool #5 (Tool Table).
The plastic sheet is
sandwiched in between the
cover and the top-beam
To Next Page
