5
APPLIANCE DIMENSIONS - AGA DC5
Fig. 2 DESN 516659
Cooker Dimensions
When surveying for a cooker installation the actual clearance required for the ‘body’ of the
appliance should be increased by 10mm beyond the figures quoted above. This allows safe
margin to take into account the natural dimensional variations found in major castings. In
particular the width across the appliance recess could be critical.
APPLIANCE WEIGHT (Excludes Packaging)
Model: AGA Dual Control (DC3) - 444kg
Hotcupboard - 110kg
A B C D E F G H J K L M N P Q R
mm 1478 948 910 680 1388 760 1145 698 116 10 536 849 30 634 448 813
