MAINS CABLE ROUTING - AGA DC3
Fig. 4 DESN 516643
MAINS CABLE FED FROM
CONTROL TRAY LEFT OR
RIGHT EXIT THROUGH
DUCTING DEPENDENT UPON
POSITION OF SUPPLY SOCKET
9
Fig. 4A DESN 516105
THE MAINS SUPPLY CONNECT POINT MUST BE WITHIN THE ZONES SHOWN
