22
800 mm (31 ½”)
580 mm
(22 /”)
60 mm
(2 /”)
25 mm
(1”)
Supply Pipe
Rear Panel
Rear Wall
AGA Hearth Level
Approx position
of supply pipe
Centre Line
Front View
Plan View
Fig. 9.3
Gas Supply Connections
DESN 511647
