GENERAL INFORMATION
Thank you for buying the LT300 laser! Although the LT300 is very simple
to use, we recommend that you read this manual before operating the laser.
Description
The LT300 is a visible laser that can be used for levelling, vertical alignment & squaring.
It’s totally waterproof and also has scanning and constant squaring for interior jobs.
Other advanced features include: totally automatic self-leveling in both horizontal
and vertical modes; electronic calibration by the user; and optionnal remote control.
Specifications
Recommended use 1,000 ft. (300 m) diameter
Accuracy ± 0.010%
(+/- 10 mm at 100 meters)
Levelling range ± 8%
Rotation speeds 0, 90, 150, 300, 450, 600 rpm
Scanning lengths From 2 to 35°
Manual Grade 5° on both X & Y axis
Laser battery NiCad rechargeable
Charging time 15 hours
Battery life 40 hours
Dimensions 5” x 4 1/2” x 8 1/2”
12.5 x 11.5 x 21.9 cm
Weight 7 3/4 lbs. (3.5 kg)
Environmental IP67
Laser Diode Visible 635 nm<2mW
FDA/CDRH: Class IIIA
IEC : Class IIIR
CAUTION
The LT300 is a Class IIIR / Class IIIa laser and is man-
ufactured to comply with the international rules of safe-
ty IEC285. Althouth the power of the emission of the
beam does not exceed 5mW in Class IIIR, the following
cautions are recommended :
• Do not stare directly at the beam
• Do not set up the laser at eye level
