SAFETY
LOCKUP DEVICE
With the implement fully raised, install cylinder
lockup channel on main lift cylinder (Fig.14 ). Install
pin through channel to hold channel in position.
WARNING! ALWAYS INSTALL LOCKUP WHEN
WORKING UNDER OR AROUND
IMPLEMENT AND WHEN
TRANSPORTING IMPLEMENT.
When not in use, store lockup channel on front
frame cross member support (Fig.15 ).
10
Fig. 14 - Cylinder Lockup
1. Lockup Installed
Fig. 15 - Cylinder Lockup Storage
1. Storage Location
