Filmlauf / Film Drive / Avance film
AGFA MSC 200 / MSC 100
16.06.99 /PN 8043
3.29
Negativbühne / Negative Carrier / Porte-négatif 8.8506.5000.2
Pos. Teil-Nr. ABC Bezeichnung Bemerkungen
Item no. Part no. Code Description Remarks
Pos. No. de ref. Désignation Remarques
0 9.8506.1340.0
QZCL7 Reinigungsstreifen 135 für Filmantriebsrollen TR4, TR5 2 Stück
Cleaning strips 135 for filmdrive rollers TR4, TR5 2 pcs.
Bande nettoyage 135 pour rouleau TR4, TR5 2 pcs.
0 9.8506.5000.2
Negativebühne vollständig
Negative carrier assy
Porte-nègatif complet
1 9.8506.8420.1
Kable 110mm VS 127 - KA 24 - VS 114
Cabel 110mm VS 127 - KA 24 - VS 114
Câble 110mm VS 127 - KA 24 - VS 114
2 9.8506.5041.0
Winkelhebel
Bracket lever
Equerre levier
3 9.8506.5080.0
QTUVF Brücke genietet
Bridge mounted
Pont montèe
4 9.8506.5042.0
Achse
Shaft
Axe
5 9.8506.9240.1
QTK8X NC-Distributor Karte GS1 NC
NC-Distributor PCB assy GS1 NC
NC-Distributor carte GS1 NC
6 9.8506.8410.1
Q3JVA Flachbandkabel VS 119 - FK 26 - VS 120
Flat Cable VS 119 - FK 26 - VS 120
Câble flat VS 119 - FK 26 - VS 120
7 9.8506.5072.0
Führungsleiste rechts
Plate guide right
Bande guide à droite
8 9.8506.5071.0
Führungsleiste links
Plate guide left
Bande guide à gauche
9 9.8506.5055.1
Druckfeder
Pressure spring
Ressort à pression
10 9.8506.8870.0
Hubmagnet
Solenoid
Aimant
11 9.8506.5045.0
Druckfeder
Tension spring
Ressort a pression
12 9.8506.5046.0
Dämpfungsscheibe
Damping washer
Disque d´amortissement
13 9.8506.9550.1
Q25KW Magnet Vorverstärker Platine
Magnet Preamplifer PCB Assy
Magnet Preamplifer Platine
14 9.8506.5082.0
Druckfeder
Pressure Spring
Ressort à pression
15 9.8506.8425.2
Kabel KA32 VS 165 - KA 32 - VS 166
Cabel KA32 VS 165 - KA 32 - VS 166
Câble KA32 VS 165 - KA 32 - VS 166
16 9.8506.5170.0
Q4TVQ Haltewinkel
Bracket
Equerre de fixation
17 9.8506.5061.1
Abdeckung
Cover
Rèvetement
18 9.8506.5081.0
Kegelstift
Taper pin
Goupille conique
19 9.8506.5006.0
Velourstreifen
Protective strip
Bande de protection
