50 5975/5977 Series MSD Operation Manual
3 Operating in Electron Ionization (EI) Mode
To enable/disable LVDS on MSD
1 Press Config, and then press MS/Aux Det to bring up the CONFIGURE MS
DETECTOR menu.
2 Press the down arrow to scroll to Lvds communication.
If you want to enable the LVDS, press On/Yes.
If you want to disable the LVDS, press Off/No.
3 Wait for the MSD to confirm the change on the GC control panel.
