Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
R18 6031A 0683-1005 res 10 10% 1/4W
6035A 0811-3842 res 600 10% 10W
R20 6030A, 35A 0811-3731 res 1.2 K% 2W
T1 6031A 9170-0061 magnetic-core (jumper 8150-4777)
TS1 all 3103-0081 switch, thermal +202F
U1 all 1826-0346 IC op amp
VR1 all 1902-0575 diode, zener 6.5 V 2%
A5 Mechanical
6030A,35A 5020-2877 heatsink (CR5)
6030A,35A 5020-2878 heatsink (CR4, Q1)
6030A,35A 0340-1123 insulator (L1,2) (6)
6030A,35A 1251-7600 socket pin (Q1) (2)
6031A 06011-20001 heatsink (CR1,CR5)
6031A 1205-0520 heatsink (Q1)
6031A 1205-0398 heatsink (Q2)
6031A 0380-1524 standoff, hex (4)
6031A 06011-00001 bracket (CR1, CR5 heatsink)
6032A 06032-00018 heatsink (CR4,Q2)
6032A 1205-0398 heatsink (Q1)
6032A 1251-7600 socket pin (Q2) (2)
6032A 0380-1524 standoff, hex (4)
6032A 06032-00017 bracket (CR4, Q2 heatsink)
A6
6030A,31A,32A 5060-3522
AC Input Filter
6035A 06011-60028 ''
C101 6030A,31A,32A 0160-4355
cap 0.01
µF 10% 250Vac
6035A 0160-4048
cap 0.022
µF 10% 250Vac
C102 6030A,31A,32A 0160-4281 cap 2200pF 20% 250Vac
6035A 0160-4439
cap 0.0047
µF 10% 250Vac
C103 6030A,31A,32A 0160-4355
cap 0.01
µF 10% 250Vac
6035A 0160-4048
cap 0.022
µF 10% 250Vac
C104 6030A,31A,32A 0160-4281 cap 2200pF 20% 250Vac
6035A 0160-4439
cap 0.0047
µF 10% 250Vac
C105 all 0160-4962
cap 1
µF 20% 250Vac
C106, 107 6030A,31A,32A 0160-4183 cap 1000pF 20% 250Vac
6035A 0160-4439
cap 0.0047
µF 10% 250Vac
C108, 109 all 0160-4962
cap 1
µF 20% 250V
L101 all 66000-80004 choke, input
R101 all 0686-3945 res 390K 5% 0.5W
W101-103 all 1251-5613 connector, single
A6 Mechanical
all 0360-2217 terminal block 3-position
