Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
A8
all 5063-3463
GPIB Board
C1 all 0160-5422
cap 0.047
µF 20% 50V
C2,3 all 0160-4807 cap 33pF 5% 100V
C4 all 0160-5422
cap 0.047
µF 20% 50V
C5 all 0160-4822 cap 1000pF 100V
C6 all 0180-0197
cap 2.2
µF 10% 20V
C7,8 all 0160-4807 cap 33pF 5% 100V
C9 all 0160-5422
cap 0.047
µF 20% 50V
C10 all 0160-4801 cap 100pF 5% 100V
C11,12 all 0160-5422
cap 0.047
µF 20% 50V
C13 all 0160-4801 cap 100pF 5% 100V
C14 all 0160-4832
cap 0.01
µF 10% 50V
C15 all 0160-5422
cap 0.047
µF 20% 50V
C16 all 0160-4801 cap 100pF 5% 100V
C22 all 0180-3798
cap 4700
µF 25V
C23 all 0180-4136
cap 10
µF 10% 20V
C24 all 0180-0393
cap 39
µF 10% 10V
C25,26 all 0160-5422
cap 0.047
µF 20% 50V
C27 all 0180-0374
cap 10
µF 10% 20V
C28-31 all 0160-5469
cap 1
µF 10% 50V
C32-37 all 0160-5422
cap 0.047
µF 20% 50V
C38 all 0180-0116
cap 6.8
µF 10% 35V
C39,40 all 0160-5422
cap 0.047
µF 20% 50V
C41,42 all 0160-4820 cap 1800pF 5% 100V
C43-47 all 0160-5422
cap 0.047
µF 20% 50V
C48 all 0180-0116
cap 6.8
µF 10% 35V
C49-51 all 0160-5422
cap 0.047
µF 20% 50V
C52 all 0160-4822 cap 1000pF 100V
C53-58 all 0160-5422
cap 0.047
µF 20% 50V
C59,60 all 0160-4822 cap 1000pF 100V
C61 all 0160-4830 cap 2200pF 10% 250V
C62,63 all 0160-4807 cap 33pF 5% 100V
C64 all 0160-5422
cap 0.047
µF 20% 50V
C65 all 0180-0393
cap 39
µF 10% 10V
C66 all 0160-5422
cap 0.047
µF 20% 50V
C67-70 all 0160-4832
cap 0.01
µF 10% 50V
C71,73 all 0160-4830 cap 2200pF 10% 250V
C142 all 0160-4801 cap 100pF 5% 100V
C143,144 all 0160-5422
cap 0.047
µF 20% 50V
D8,9 all 1901-0731 diode, power rectifier
D13-17 all 1901-1098 diode, switching
D20,21 all 1901-1080 diode, 1N5817
D22 all 1901-1098 diode, switching
F1,2 all 2110-0712 fuse, 4AM, 125V
J1,2 all 1251-7330 telephone jacks
J3 all 1200-0485 right angle socket
J4 all 1252-0268 GPIB connector
J5 all 1251-4926 connector 8-contact
J6 all 1251-4927 connector 16-contact
J7,8 all 1251-8417 connector 16-contact
