97
Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
J9 all 1251-4927 connector 16-contact
J10 all 1251-5384 connector 3-contact
L1 all 9170-1680 choke
L2-4 all 9170-1454 core-shield bead
Q1,4 all 1853-0089 transistor 2N4917
R1 all 0757-0457 res 47.5 1% 1/8W
R2 all 0698-3155 res 4.64K 1% 1/8W
R3 all 0757-0442 res 10K 1% 1/8W
R4 all 0698-3155 res 4.64K 1% 1/8W
R5 all 0683-1065 res 10M 5% 1/4W
R6 all 0698-4037 res 46.4 1% 1/8W
R7 all 0698-3155 res 4.64K 1% 1/8W
R8-11 all 0757-0401 res 100 1% 1/8W
R12 all 0698-3155 res 4.64K 1% 1/8W
R14 all 0698-0082 res 464 1% 1/8W
R15-17 all 0698-4037 res 46.4 1% 1/8W
R18 all 0757-0280 res 1K 1% 1/8W
R19 all 0698-8827 res 1M 1% 1/8W
R20-22 all 0698-3155 res 4.64K 1% 1/8W
R23 all 0698-0082 res 464 1% 1/8W
R24,26 all 0698-3156 res 14.7K 1% 1/8W
R28 all 0699-0059 res 5K 0.1% 1/10W
R29 all 2100-3353 trimmer 20K 10%
R30 all 0699-0642 res 10K 0.1% 1/10W
R32 all 0757-0457 res 47.5K 1% 1/8W
R33 all 0698-6360 res 10K 0.1% 1/8W
R34 all 0757-0401 res 100 1% 1/8W
R35 all 0699-0059 res 5K 0.1% 1/10W
R36 all 0757-0316 res 42.2 1% 1/8W
R37 all 0699-0642 res 10K 0.1% 1/10W
R39 all 0757-0270 res 249K 1% 1/8W
R40 all 2100-3353 trimmer 20K 10%
R41 all 0757-0401 res 100 1% 1/8W
R42 all 0757-0411 res 332 1% 1/8W
R43 all 0699-0059 res 5K 0.1% 1/10W
R44 all 0757-0316 res 42.2 1% 1/8W
R45 all 0699-0642 res 10K 0.1% 1/10W
R46 all 0757-0411 res 332 1% 1/8W
R48 all 0757-0457 res 47.5K 1% 1/8W
R49 all 0698-6360 res 10K 0.1% 1/8W
R50 all 0757-0401 res 100 1% 1/8W
R51 all 2100-3353 trimmer 20K 10%
R52 all 0698-3156 res 14.7K 1% 1/8W
R55,58 all 2100-3732 trimmer 500 10%
R59,60 all 0698-3558 res 4.02K 1% 1/8W
R61 all 2100-3732 trimmer 500 10%
R62-64 all 0698-3558 res 4.02K 1% 1/8W
R65 all 0757-0280 res 1K 1% 1/8W
R66 all 0698-3558 res 4.02K 1% 1/8W
R67 all 0698-6320 res 5K 0.1% 1/8W
