Chapter 10 399
Analyzer Options and Block Diagrams
Option Descriptions
Option 041 allows the analyzer to copy its screen to a printer or plotter,
and includes a separate connector that accepts programming
commands from an external keyboard.
Option 041 is also available as a retrofit kit (Option R41) after the
purchase of your analyzer, or as a kit part number 08590-60380.
NOTE Option 041 can be converted to an Option 043 by ordering the RS-232
and parallel interface connector assembly
part number 08590-60369.
RS-232 and Parallel Interface (Option 043)
Option 043 allows you to control your analyzer from a computer that
uses an RS-232 interface bus. Such computers include the Vectra PC,
the IBM PC, the AT, and compatibles. It includes a connector for an
external keyboard, an RS-232 9-pin connector, a parallel interface
connector for printers, and the 8590 E-Series and L-Series Spectrum
Analyzers, and 8591C Cable TV Analyzer Programmer's Guide.
Option 043 allows the analyzer to copy its screen to a printer or plotter,
and includes a separate connector that accepts programming
commands from an external keyboard.
Option 043 is also available as a retrofit kit (Option R43) after the
purchase of your analyzer, or as a kit part number 08590-60381.
NOTE Option 043 can be converted to an Option 041 by ordering the IB and
parallel interface connector assembly part number 08590-60368.
Frequency Extension to 26.5 GHz with APC-3.5
Connector (Option 026)
For 8592L and 8593E only. The frequency range of the analyzer is
extended from 22 GHz to 26.5 GHz. Analyzers with this option use an
APC-3.5 connector on the RF INPUT, and circuit boards and front
panels that are different from the standard units.
Frequency Extension to 26.5 GHz with N-Type
Connector (Option 027)
For 8592L and 8593E only. The frequency range of the analyzer is
extended from 22 GHz to 26.5 GHz. Analyzers with this option use an
N-Type connector on the RF INPUT, and circuit boards and front panels
that are different from the standard units.
