400 Chapter10
Analyzer Options and Block Diagrams
Option Descriptions
NOTE The extended frequency specifications only apply when using the
Type-N to SMA adaptor that is supplied with the option.
Front Panel Protective Cover (Option 040)
The impact cover assembly snaps onto the front of your analyzer to
protect the front panel during travel and when the unit is not in use.
Option 040 is also available as a kit (Impact Cover Assembly,
part number 5062-4805).
Protective Soft Carrying Case/Back Pack
(Option 042)
A soft carrying case/backpack with a pouch for accessories. Option 042
can be used to provide additional protection during travel. (Cannot
operate instrument while installed in case.)
Improved Amplitude Accuracy for NADC bands
(Option 050)
For 8591E, 8593E, 8594E, 8595E, and 8596E only. Improved amplitude
accuracy for NADC. This is an amplitude calibration that improves
specifications to ±0.7dB at 20-30 °C for: NADC frequency bands 824 to
849 MHz and 869 to 894 MHz.
Option 050 is also available as a service center only retrofit kit
(Option R50) after the purchase of your analyzer.
Improved Amplitude Accuracy for PDC bands
(Option 051)
For 8591E, 8593E, 8594E, 8595E, and 8596E only. Improved amplitude
accuracy for the high and low frequency bands of PDC. This is an
amplitude calibration that improves specifications to ±0.5 dB at
20-30 °C for the PDC frequency bands in the 810 to 956 MHz and 1429
to 1501 MHz frequency ranges.
Option 051 is also available as a service center only retrofit kit
(Option R51) after the purchase of your analyzer.
