Step 2. Turn on the oscilloscope
The next few steps (turning on the oscilloscope, loading the default setup,
and inputting a waveform) will provide a quick functional check to verify
the oscilloscope is operating correctly.
1 Connect the power cord to a power source.
Use only power cords designed for your oscilloscope.
Use a power source that delivers the required power.
Table 2 Power Requirements
Name Typical Value
Line rating: ~Line 50 W max
100-120 V/50/60/400 Hz, ±10%
100-240 V/50/60 Hz, ±10%
To avoid electric shock, be sure the oscilloscope is properly grounded.
