1Getting Started
28 Agilent 1000B Series Oscilloscopes User’s Guide
Step 7. Become familiar with the Front Panel Controls
Before using the oscilloscope, familiarize yourself with the front panel
controls.
The front panel has knobs, keys, and softkeys. Knobs are used most often
to make adjustments. Keys are used for run controls and to change other
oscilloscope settings via menus and softkeys.
Entry knob Horizontal controls Run controls
Menu controlsVertical controls Trigger controls
Softkeys
Setup and File controls
Math functions Reference waveforms
Figure 6 Front Panel
